Product Specification
Model
Spec
PC
LCD Display 17" active matrix TFT LCD panel
Pixel pitch 0.264(H)x0.264(V) mm
Max Resolution 1280(H)x1024(V)SXGA
Dimensions 198(D)x397H)x374(W) mm
Packing Dimensions 145(D)x460(H)x418(W) mm
Contrast Ratio 450:1
Brightness 300cd/m2
Response Time 8ms
Display Colour 16.7M
Viewing Angle L/R +75 °~-75 °
U/D +70° ~-60 °
PC Interface Video
Sync
RGB analog 0.7Vp p
Display Mode VGA/SVGA/XGA/SXGA
PC connector 15 pin D-sub
Front Control Power on/off with LED, Menu select, Up/Down
Adjustment, Source
OSD Adjustment Contrast, Brightness, Auto tuning, Phase, Clock,
Position, Input selection
Audio speaker 2W
Power input AC Input:100~240V/1.2A,50-60Hz
Operating
Consumption
42W
Operating Conditions
Temperature:0℃-40℃Humidity: 20%-80%
Storage Conditions
Temperature:-10℃-60℃Humidity: 20%-80%
Certification FCC(DOC), CE, TUV
Weight N/W:3.6Kgs G/W:4.7Kgs
