Inputs Diagram
Inputs
1. AC POWER INPUT: AC inlet for 100-240V power system.
2. PC INPUT: This D-sub 15 sockets can be connected to a PC.
3. S-VIDEO INPUT: Inputs S-video signal by DIN socket.
4. VIDEO-IN: This BNC socket can be connected to composite video output.
Display Angle
Tilting
For viewing clarity, you can tilt the LCD forward (Down to 5 degrees) or backward (Up to 18
degrees).
Down 5°
Up 18°
