EdgeStar AP10000HW User Manual

14
Maintenance – Extending the Drain Tube
The drain tube may be extended by adding
an extension tube and using a suitable
connector.
FIG.17
Please note
1. The drain must be at or below the
outlet level.
2.
Flashing Comp / Water indicator will
not function in this mode of
drainage.
3. This unit will not shut off when an
external drain pan/tray is filled.
4. If you want to extend the water
tube, you can connect it with
another tube (Diameter: 0.71”)
5. When the room humidity is over
85%, we recommend continuous
drainage.
FIG.18
Drain tube
Original
drain tube
Extended drain tube
(Outer Diameter:
0.71”)

EdgeStar AP10000HW Specifications

General

Description of Product	EdgeStar Portable Air Conditioner
Model	AP10000HW
Refrigerant	R22/15.2 OZ
Voltage / Frequency	115 V, 60 Hz
Power / Ampere Consumption for cooling	830W / 7.9 A
Power / Ampere Consumption for heating	920W / 8.2 A
Maximum Dehumidifying Capacity	50 pints/day
Fan speeds	2 (High and Low)
Timer	1- 12 hours

Weight and Dimensions

Net Weight	51 lbs.
Dimensions	12 3/8” x 14 1/16” x 27 15/16” (WxDxH)
