EdgeStar AP10000HW User Manual

6
Parts Identification
Front Back
1. Display
2. Control panel
3. Buttons
4. Front air vent
5. Handle
6. Caster
7. Cord storage
8. Air pre-filter
9. Air inlet (evaporator)
10. Exhaust air outlet
11. Air inlet (condenser)
12. Water stopper/drainage point
Accessories
13. Flat adapter - for insertion over
hose and into window kit.
14. Exhaust hose
15. Active carbon filter
16. Extendable window kit
17. Drain tube for continuous
drainage
18. Remote control

EdgeStar AP10000HW Specifications

General

Description of Product	EdgeStar Portable Air Conditioner
Model	AP10000HW
Refrigerant	R22/15.2 OZ
Voltage / Frequency	115 V, 60 Hz
Power / Ampere Consumption for cooling	830W / 7.9 A
Power / Ampere Consumption for heating	920W / 8.2 A
Maximum Dehumidifying Capacity	50 pints/day
Fan speeds	2 (High and Low)
Timer	1- 12 hours

Weight and Dimensions

Net Weight	51 lbs.
Dimensions	12 3/8” x 14 1/16” x 27 15/16” (WxDxH)
