EdgeStar AP10000HW User Manual

9
Installation – Exhaust Hose
Use the hose provided and
attach the exhaust hose to
the back of the air
conditioner.
Avoid kinks and bends in
the exhaust hose as this will
cause the unit to work less
efficiently. Improper setup
may cause the unit to
overheat and shut off. Figs.
8 & 9 show the correct
position
The hose may be extended
from 11” to 59.” For
maximum efficiency use the
shortest length possible.
WARNING!
The length of the exhaust hose
is specially designed according
to the specification of this
product. Longer hoses are not
recommended.
FIG.8
FIG.9
FIG.10
FIG.11

EdgeStar AP10000HW Specifications

General

Description of Product	EdgeStar Portable Air Conditioner
Model	AP10000HW
Refrigerant	R22/15.2 OZ
Voltage / Frequency	115 V, 60 Hz
Power / Ampere Consumption for cooling	830W / 7.9 A
Power / Ampere Consumption for heating	920W / 8.2 A
Maximum Dehumidifying Capacity	50 pints/day
Fan speeds	2 (High and Low)
Timer	1- 12 hours

Weight and Dimensions

Net Weight	51 lbs.
Dimensions	12 3/8” x 14 1/16” x 27 15/16” (WxDxH)
