EdgeStar AP12005ECO User Manual

7
Attaching the duct
connectors to the exhaust
hose
A.
B.
5. Attach the connectors to the hose:
A. Extend the ends of the exhaust hose
B. Thread the duct connector on by turning it clockwise until
it stops.
2
0
”
6. Roll the unit towards the window kit. Leave a space that
is at least 20 inches to the wall.





EdgeStar AP12005ECO Specifications

General

Description of product	Portable Air Conditioner
Model	AP12005ECO
Color	Silver
Coolant	R410A
Voltage/Frequency	115V/60Hz
Input Power	900W
Current	9.5A
Timer	24 Hour

Weight and Dimensions

Dimensions H x W x D	30.9” x 17.1” x 15”
Weight	67 lbs
