EdgeStar AP12005ECO User Manual

11
Remote Control LCD Indicators
Indicators
Transmitter Appears when the Power or Timer button is
signaling the unit.
Fan Speed Shows the set fan speed between
Automatic, High, Medium and Low.
Mode Shows the set mode between Automatic,
Cooling, Dehumidify, Fan Only.
Temperature Setting Shows the set temperature.
Fahrenheit and
Celsius
Shows if the set temperature is in Fahrenheit
or Celsius.
Clock Shows the Clock’s time. The remote control
has a 24-Hour clock.
Timed Hours Shows the number of timed hours when the
Timer is enabled.
Timer Shows if the On Timer or Off Timer is enabled.
Mode Indicator Function
Automatic
The unit will cool, dehumidify or heat (some
models) depending on the ambient
temperature. The mode and fan speed
changes automatically. The front panel lights
will change to reflect the running mode.
Cooling
The unit will cool. The front panel lights will be
blue.
Dehumidify
The unit will remove moisture from the air. The
front panel lights will be yellow.
Fan Only
The unit will run as a fan and circulate air. The
front panel lights will be green.
Fahrenheit and
Celsius Indicator
Timer Indicator
Timed Hours
Clock Indicator
Mode Indicators
Speed Indicators
Transmitter Indicator
Temperature Setting Indicator

EdgeStar AP12005ECO Specifications

General

Description of product	Portable Air Conditioner
Model	AP12005ECO
Color	Silver
Coolant	R410A
Voltage/Frequency	115V/60Hz
Input Power	900W
Current	9.5A
Timer	24 Hour

Weight and Dimensions

Dimensions H x W x D	30.9” x 17.1” x 15”
Weight	67 lbs
