EdgeStar AP8000W Service Manual

6
NO.
PART NAME
NO.
PART NAME
1
BASE PAN
34
TOP COVER PLATE
2
CASTOR
35
TOP COVER PLATE
3
PLUG
36
POWER SUPPLY CORD
4
FAN BRACKET
37
BRACKET
5
FAN MOTOR
38
BRACKET
6
BLADE
39
SHOCK ABSORBER
7
DRAIN BUCKET COVER
40
SIDE PANEL
8
TANK LID
41
SIDE PANEL
9
FLOAT
42
FRONT PANEL
10
FLOAT SWITCH
43
LOUVER
11
DRAINAGE PAN
44
FAN AIR DEFLECTOR
12
COMPRESSOR
45
AIR FILTER
13
RUBBER FOOT
46
REAR PANEL
14
CONDENSER
47
INTAKE GRILLE
15
EVAPORATOR
48
INTAKE GRILLE
16
DISCHARGE PIPE
49
COVER
17
SUCTION PIPE
50
FIXTURE
18
CAPILARY TUBE
51
COVER
19
FILTER DRYER
52
BRACKET
20
FAN HOUSING
53
PLUG
21
FAN HOUSING
54
SENSOR
22
FAN HOUSING
55
CONTROL PANEL
23
FAN HOUSING
56
HEAT EXHAUST HOSE
24
BLOWER WHEEL
57
DUCT CONNECTOR
25
BLOWER WHEEL
58
DUCT CONNECTOR
26
FAN MOTOR
59
GRATED ADAPTER
27
CAPACITOR FOR COMPRESSOR
60
EXHAUST COVER
28
BRACKET
61
REMOTE CONTROL
29
CAPACITOR FOR FAN
62
BATTERY
30
MAIN PCB
63
WINDOW PLATE
31
CONTROL BOARD
64
WINDOW PLATE W/ HOLE
32
MAIN PCB BRACKET
65
SCREW
33
MAIN PCB COVER
66
CARBON FILTER

EdgeStar AP8000W Specifications

General

Description of product	Portable Air Conditioner
Model	AP8000W
Color	White
Voltage/Frequency	AC 115V~60Hz
Input Power	840W
Current	7.9A
Dehumidifying capacity	71 Pints/Day
Timer	24 Hour
Coolant	R-410A

Weight and Dimensions

Dimensions WxHxD	19 1/4” 24 3/4” x13 1/4”
Weight	56 lbs
