EdgeStar VBR Series User Manual

SENSOR RESISTANCE TABLE
No.
Measured Temperature (C °)
RESISTANCE OF SENSOR (kΩ)
1
-30
116.55
2
-28
104.97
3
-26
94.67
4
-24
85.49
5
-22
77.30
6
--20
69.99
7
-18
63.44
8
-16
57.58
9
-14
53.32
10
-12
47.60
11
-10
43.35
12
-8
39.53
13
-6
36.08
14
-4
32.97
15
-2
30.16
16
0
27.62
17
2
25.32
18
4
23.24
19
6
21.35
20
8
19.63
21
10
18.07
22
12
16.65
23
14
15.35
24
16
14.17
25
18
13.10
26
20
12.11
27
22
11.21
28
24
10.39
29
25
10.00
30
26
9.63
31
28
8.94
32
30
8.30
33
32
7.72
34
34
7.18
35
36
6.69
36
38
6.23
37
40
5.81
38
42
5.42
39
44
5.06
40
46
4.73
41
48
4.43
42
50
4.15
• The tolerance of sensor resistance is ±5%
• Be sure to measure the sensor resistance after keeping the sensor more than 3 minutes
at a measuring temperature. (It needs delay due to sensor speed.)
