3-18
Selection Guide
OUTBOARD–SPLASHWELL
MOUNT
36" (914mm) MAXIMUM ENGINE CENTRE DISTANCE
26" (660mm) MINIMUM ENGINE CENTRE DISTANCE
Tie Bar Kit# HO5010
Mounting Configuration
General Dimensions
PART# HC5380
NOTICE
DO NOT use a PRO Helm pump with this,
or any other unbalanced steering cylinder.
