1. Drill hole in the wall
2. Fix screw on the wall
Place Satellite Speaker onto the Wall
As the illustration shows, drill a hole (Depth: 40mm/1.5", Hole size: 8mm/1/4") in the wall. If wants to place all satellite
speakers onto the wall, you can continue to drill another hole in the wall.
Note:
Dimension of the hole may vary depending on wall materials, please adjust drill size to existing conditions for proper
installation.
Hole depth: 40mm/1.5"
Hole size: 8mm/1/4"
Knock a wall anchor into the hole, then tightly twist a screw into the wall anchor.
Tips:
• Self-tapping screw: diameter: 5mm, length: 40mm; Plastic wall anchor: 8*40mm.
• 6-8 millimeters of the screw should be kept outside the wall.
