Edimax BR-6204WG User Manual

89
4.3 Reset
You can reset the router’s system should any problem exist. The reset
function essentially
Re-boots your router’s system
Parameters Description
Reset In the event that the system stops responding
correctly or in some way stops functioning, you can
perform a reset. Your settings will not be
changed. To perform the reset, click on the
<APPLY> button. You will be asked to confirm your
decision. The reset will be complete when the
power light stops blinking. Once the reset process
is complete you may start using the router again.

Edimax BR-6204WG Specifications

General

Rack mounting	-
xDSL connection	Yes
Dimensions (WxDxH)	187 x 100 x 30 mm
Power requirements	12V 1A DC
Mobile network connection	No
Maximum data transfer rate	0.1 Gbit/s
Ethernet LAN (RJ-45) ports	4
Firewall security	Network Address Port Translation (NAPT)
Security algorithms	WPA2, 64-bit WEP, 128-bit WEP, WPA
VPN support	VPN Pass Throught (IPSec/PPTP)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Flash memory	2 MB
Certification	FCC Class B, CE Mark, C-Tick
Internal memory	16 MB
Processor model	Realtek RTL8186
Antenna connector type	RP-SMA
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Product color	White
Power source type	DC

Weight and Dimensions

Depth	113 mm
Width	196 mm
Height	30 mm
