Edimax BR-6428nS V2 Brochure & Specs

Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors. Product specifications and design are subject to change without notice.
Copyright © 2013 Edimax Technology Co. Ltd. All rights reserved.
www.edimax.com
www.edimax.com
BR-6428nS V2
N300 Multi-Function Wi-Fi Router
Three Essential Networking Tools in One
Guest Network*
Supports a guest network to provide connectivity while
isolating guests from your primary network.
*Router mode only
Green Technology
Designed with the latest green technology, the BR-
6428nS V2 uses 30% less power compared to other
standard 300Mbps routers.
Wireless Internet Service Provider (WISP)
Connection Mode
With WISP support, the BR-6428nS V2 is able to
share an Internet connection from a wireless ISP
access point and convert it into a wired or wireless
network for multiple users in your home or office.
5dBi High Gain Antenna
Employs two 5dBi high gain antennas to enhance
wireless range and coverage, providing powerful
penetration through walls and floors.

Edimax BR-6428nS V2 Specifications

General

VPN support	PPPoE, static IP, dynamic IP, PPTP and L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Antennas quantity	2
Antenna gain level (max)	5 dBi
Security algorithms	WEP, WPA, WPA2
Input current	1 A
Rack mounting	-
WLAN data transfer rates supported	300 Mbit/s
Product color	White
LED indicators	Activity, LAN, Link, Power, WAN
Flash memory	4 MB
Certification	CE, FCC
Internal memory	16 MB
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Output voltage	5 V

Weight and Dimensions

Depth	110 mm
Width	135 mm
Height	28 mm
Weight	161 g
