Edimax BR-6428nS V2 User Manual

5
BrowserBasedConfigurationInterface

Aftersetupyoucanaccessthebrowserbasedconfigurationinterfaceto
configureorchangethesettingsoftheBR‐6428nSV2/nC.Toaccessthe
browserbasedconfigurationinterface,enterhttp://edimax.setupintothe
URLbarofawebbrowseronanetworkdevicewhichisconnectedtothe
BR‐6428nSV2/nC.


Ifyoucannotaccessedimax.setup,connecttheBR‐6428nSV2/nC
toacomputerusinganEthernetcableandtryagain.

Youwillbepromptedforausernameandpassword.Thedefaultusernameis
“admin”andthedefaultpasswordis“1234”.



Youwillarriveatthe“Status”screenshownbelow.Usethemenudownthe
leftsidetonavigate.Formoreinformation,refertotheusermanual.


Edimax BR-6428nS V2 Specifications

General

VPN support	PPPoE, static IP, dynamic IP, PPTP and L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Antennas quantity	2
Antenna gain level (max)	5 dBi
Security algorithms	WEP, WPA, WPA2
Input current	1 A
Rack mounting	-
WLAN data transfer rates supported	300 Mbit/s
Product color	White
LED indicators	Activity, LAN, Link, Power, WAN
Flash memory	4 MB
Certification	CE, FCC
Internal memory	16 MB
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Output voltage	5 V

Weight and Dimensions

Depth	110 mm
Width	135 mm
Height	28 mm
Weight	161 g
