Settings – Multi DMZ
Multi DMZ Edit
• Enable – To activate or deactivate the current DMZ entry.
• WAN – The WAN (WAN1, WAN2) port applied to the current DMZ entry.
• Name – To identify the current DMZ entry.
• Public IP –The public IP (or PPPoE session) that the current DMZ entry
is bound on.
• Private IP (LAN) –The IP address of the server in the DMZ
• Access Group –To specify which Access Group will be applied. Each
Access Group has its own access rules.
• Default : Applies the access rules for the Default Group.
• Group1 ~ Group4 : Applies the access rules for Group1~Group4,
respectively
• Direction –To specify in which direction the Access Group will be
applied: Outgoing, Incoming, Both.
Multi DMZ List
The List shows details of all DMZ that are currently defined.
