Also, some Status and Error conditions are indicated by combinations
of LEDs, as shown below
LED Action Condition
WAN1 LINK/ACT & 10M/100M LEDs flash alternatively. Firmware Download in progress.
WAN1 LINK/ACT & 10M/100M LEDs flash concurrently. MAC address not assigned.
WAN1 LINK/ACT & 10M/100M LEDs solid On SDRAM error
WAN2 LINK/ACT & 10M/100M LEDs solid On Timer/Interrupt error
LAN1 LINK/ACT & 10M/100M LEDs solid On LAN/WAN error
