EW-7301APg/EW-7302APg
User Manual
9
Chapter 3. Base Installation
Hardware Installation
Package Contents
The standard package contents of EW-7301APg/EW-7302APg:
y EW-7301APg/EW-7302APg x 1
y Quick Installation Guide x 1
y CD-ROM (with User Manual and QIG) x 1
y PSE with AC cable x 1
y Mounting Kit x 1
y Waterproof Connector Pack x 1
Warning: It is highly recommended to use all the supplied components other than any substitute to ensure best
performance of the system.
Panel Function Descriptions
EW-7301APg Front Panel
1. Power: Green LED ON indicates power on, and OFF indicates power off.
2. WLAN: Green LED ON indicates system ready.
3. Ethernet: Green LED ON indicates connection, OFF indicates no connection, and BLINKING
indicates transmitting data.
4. PoE Connector: For connection to PSE.
