EW-7301APg/EW-7302APg
User Manual
90
Repeater Information
Detailed information on the repeater function can be reviewed in this page.
• Repeater Status:
¾ Status: The status of the repeater, either Enabled or Disabled.
¾ Mode: The mode selected for the repeater function, either Universal Repeater or WDS.
¾ Encryption: The encryption type used, none, WEP, or WPA-PSK.
• Universal Repeater: This table will appear when Universal Repeater is enabled; table for WDS Repeater will be
displayed when WDS mode is used.
¾ SSID: SSID of the upper-bound AP to be associated with.
¾ Tx Rate: Indicate the transmitting rate of the Repeater.
¾ SNR: The SNR, Signal to Noise Ratio, indicates the relative signal strength to upper-bound AP.
¾ Tx Count: The accumulative number of transmission count.
¾ Tx Error: The accumulative number of transmitting error occurred.
