I-3. Hardware Overview
A. 12V DC port to connect the power adapter
B. LAN port with Power over Ethernet (PoE) IN
C. LAN port with Power over Ethernet (PoE) OUT
D. Reset the access point to factory default settings
I-4. LED Status
Off The access point is off.
Blue The access point is on.
Amber The access point is starting up.
I-5. Reset
If you experience problems with your access point, you can reset the device
back to its factory settings. This resets all settings back to default.
1. Press and hold the reset button on the access point for at least 10 seconds
than release the button.
You may need to use a pin or similar sharp object to push the
reset button.
2. Wait for the access point to restart. The access point is ready for setup
when the LED is blue.
