►FAST PRE-CONFIG FUNCTION / 50 IDS SELECTABLE
This feature enables the user to operate the unit hassle free by automatically setting the appropriate broadcasting table
information [ID] to provide a more convenient installation, easy to adjust anytime with no tools required*! This feature is
important when there are more than one HDMI modulators operating within the same TV coaxial distribution network. Τhe
user should change each unit’s broadcasting table information [ID] to be able for the end user devices to receive the channel.
The HDMI Modulator lite QUAD is pre-congured with the following IDs.
HDMI 1 / mod 1 = ID-01 / TV-1 HDMI 2 / mod 2 = ID-02 / TV-2
HDMI 3 / mod 3 = ID-03 / TV-3 HDMI 4 / mod 4 = ID-04 / TV-4
*IMPORTANT: In order to change the Channel Name, you have to use the CFG function to extract, edit
and load the modied conguration le.
Example of 7* different ID’s:
*IMPORTANT: 7 sample ID congurations, out of 50 installed in the HDMI Μodulator lite QUAD.
ID01 ID02 ID03 ID04 ID05 ID06 ID07
Name TV-1 TV-2 TV-3 TV-4 TV-5 TV-6 TV-7
LCN 1 2 3 4 5 6 7
TSID 1 2 3 4 5 6 7
ONID 1 2 3 4 5 6 7
NetworkID 1 2 3 4 5 6 7
Videopid 2101 2102 2103 2104 2105 2106 2107
audiopid 2201 2202 2203 2204 2205 2206 2207
pmtpID 2301 2302 2303 2304 2305 2306 2307
serviceID 2401 2402 2403 2404 2405 2406 2407
