Parts list
Table 1 - Parts list
Item
No.
Description Fig
Quantity
Kit No.(s) Part No.
RV3 RV5 RV8 RV12
101 H.V. stator: RV3 3 1 - - - 6 A652-01-700
101 H.V. stator: RV5 3 - 1 - - 7 A653-01-700
101 H.V. stator: RV8 3 - - 1 - 8 A654-01-700
101 H.V. stator: RV12 3 - - - 1 9 A655-01-700
102 H.V. rotor: RV3 and RV5 3 1 1 - - 6, 7 A652-01-701
102 H.V. rotor: RV8 3 - - 1 - 8 A654-01-701
102 H.V. rotor: RV12 3 - - - 1 9 A655-01-701
103 L.V. stator: RV3 and RV5 3 1 1 - - 6, 7 A652-01-702
*
103 L.V. stator: RV8 and RV12 3 - - 1 1 8, 9 A654-01-702
*
104 L.V. rotor: RV3 and RV5 3 1 1 - - 6, 7 A652-01-703
104 L.V. rotor: RV8 and RV12 3 - - 1 1 8, 9 A654-01-703
105 Oil pump stator 3 1 1 1 1 6 - 9, 20
*
106 Oil pump rotor 3 1 1 1 1 6 - 9 A652-01-705
107 End plate 3 1 1 1 1 6 - 9 A652-01-704
108 Oldham coupling (H.V.-L.V.) 3 1 1 1 1 6 - 9 A652-01-026
109 Shaft-seal sleeve 3 1 1 1 1 6 - 9, 13
110 Seal carrier 3 1 1 1 1 6 - 9, 12
111 Reed valve 3 1 1 1 1, 1 6 - 9, 20 A652-01-029
115 Oil pump blade 3 1 1 1 1 2 - 9
116 RV3 H.V. Blade 3 2 2, 6
116 RV5 H.V. blade 3 2 3, 7
116 RV8 H.V. blade 3 2 4, 8
116 RV12 H.V. blade 3 2 5, 9
117 L.V. blade: RV3 and RV5 3 2 2 - - 2, 3, 6, 7
117 L.V. blade: RV8 and RV12 3 - - 2 2 4, 5, 8, 9
118 Reed valve clamp 3 1 1 1 1 6 - 9 A210-35-129
119 Oldham coupling (L.V.-oil pump) 3 1 1 1 1 1, 6 - 9, 20 A259-08-127
120 Printed gasket (seal carrier) 3 1 1 1 1 1, 6 - 9, 12, 20 A271-60-008
123 Shaft seal (inner): 25 x 35 x 7 3 1 1 1 1 1, 6 - 9, 20 H021-09-066
124 Shaft seal (outer): 20 x 30 x 7 3 1 1 1 1 1, 6 - 9, 12, 20 H021-09-124
125 70 O-ring: 14.6 i.d. x 2.4 section
(rotor sleeve)
3 1 1 1 1 6 - 9, 13
127 O-ring: 57.6 i.d. x 2.4 section
(cartridge)
1 1 1 1 1 1, 6 - 9, 20
129 Screw: cap-head M6 x 20 (seal
carrier securing)
3 4 4 4 4 6 - 9
130 Screw: cap-head M6 x 40 (end cover
securing and LV to HV securing)
3 4 4 4 4 6 - 9
