Edwards RV3 Service Manual

© Edwards Limited 2018. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
Parts list
A652-01-840 Issue P
410 Fan (Nema motor) 1 1 1 A223-01-009
1 1 1 A223-01-009
410 Fan (ISO motor) 1 1 1 A223-01-010
1 1 1 A223-01-010
410 Fan (3-phase motor) 2 1 1 1 1 A223-01-010
411 Coupling element 1 1 1 1 1 1, 20
412 Side panel (pump logo side): RV3 1 1 - - - A652-01-017
412 Side panel (pump logo side): RV5 1 - 1 - - A653-01-017
412 Side panel (pump logo side): RV8 1 - - 1 - A654-01-017
412 Side panel (pump logo side): RV12 1 - - - 1 A655-01-017
413 Lifting plate 1 - - 1 1 A654-01-023
414 Lifting plate cover 1 - - 1 1 A259-08-141
420 Screw: cap-head M4 x 10
(side panel securing)
1 4444
421 Screw: cap-head M6 x 20
(motor securing)
1 4444
422 Screw: cap-head M6 x 12
(lifting plate securing)
1 2222
423 Screw: cap-head M6 x 40
(fan securing)
1 1111
452 Fan 1 1 1 1 1 A223-01-010
453 Motor plate 2 1111
454 Screw: cap-head M5 x 40
(fan securing)
2 1111
455 Screw: cap-head M6 x 20
(motor to motor plate securing)
2 1111
B Motor top cover 1 1111
C Shaft-seal spacer
‡
3 - - - - 1, 12, 20
D Motor starting relay (Sinpac) 1 1111 11
*
On pumps with Serial number 9721 29 224 and earlier, all items marked thus (e.g. LV stator and oil pump),
stator must be replaced at the same time. On pumps with later serial numbers, they may be replaced
individually. If you fail to observe this practice, the pump will not operate.
†
As of the end of 2010, the four RV 1-phase motors (used in kits 14, 15, 16 and 17) have been made obsolete
and replaced by two new motors (item 401). These new motors are suitable for use on all 1-phase RV3, RV5,
RV8 and RV12 pumps.
‡
Not fitted to pumps as supplied, but may be fitted as part of maintenance.
Table 1 - Parts list (continued)
Item
No.
Description Fig
Quantity
Kit No.(s) Part No.
RV3 RV5 RV8 RV12
