Edwards RV3 Service Manual

A652-01-840 Issue P
Page 6 © Edwards Limited 2018. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Parts list
301-2 Exhaust pin 1 1111
301-3 Exhaust diaphragm 1 1111
302 Inlet filter assembly 1 1 1 1 1 A223-05-067
306 Baseplate 1 1 1 1 1 A210-35-126
308 Coupling hub 1 1 1 1 1 A210-35-128
309 Reed valve baffle 1 1 1 1 1 A210-35-130
310 Oil box 1 1111
311 Sight-glass bezel 1 1111
312 Coupling element 1 1 1 1 1 116-9 A210-71-077
313 Oil filler plug 1 2 2 2 2 A259-08-118
314 Printed gasket (oil box) 1 1 1 1 1 1, 6 - 9, 20 A271-60-005
315 Rubber foot 1 4 4 4 4 A265-01-041
316 Sight-glass 1 1 1 1 1 A292-01-018
318 Outlet cover 1 1111
319 O-ring: 28.2 i.d. x 3.53 section
(outlet flange and filler plug)
1 3 3 3 3 1, 6 - 9, 20 H021-26-026
321 O-ring: 69.5 i.d. x 3.0 section
(sight-glass)
1 1 1 1 1 1, 6 - 9, 20 237-24-072
322 Oil drain plug 1 1111
323 O-ring: 15.6 i.d. X 2.4 section
(drain plug)
1 1111
325 Screw: cap-head M6 x 30
(coupling securing)
1 1111
326 Screw: cap-head M6 x 20
(baffle securing)
1 7788
327 Screw: cap-head M6 x 40
(oil box securing)
1 4444
331 Outlet label 1 1111
401 RV3/RV5/RV8 and RV12 Motor kit
(Europe/USA) 50/60 Hz, 450/550 W,
1-phase 220-240/ 230-240 V
1 1 1 1 1 22 A652-99-500
401 RV3/RV5/RV8 and RV12 Motor kit
(Japan) 50/60 Hz, 450/550 W, 1-
phase 100-200/ 200-210 V
1 1 1 1 1 23 A652-98-500
401
†
Motor assembly: RV3 and RV5
(1-phase)
1 1 1 - - 14, 16
401
†
Motor assembly: RV8 and RV12
(1-phase)
1 - - 1 1 15, 17
401 Motor assembly: RV3 and RV5
(3-phase)
2 11 18
401 Motor assembly: RV8 and RV12
(3-phase)
2 11 19
403 Oil box label 1 1111
405 Lifting handle 1 1 1 - - A259-08-125
408 Side panel (mode selector side) 1 1 1 1 1 A652-01-018
409 Ducting sheet 1 1 1 1 1 A652-01-019
410 Fan 1 1 1 1 1 A223-01-007
Table 1 - Parts list (continued)
Item
No.
Description Fig
Quantity
Kit No.(s) Part No.
RV3 RV5 RV8 RV12
