Parts list
A652-01-840 Issue P
131 M6 x 30 cap screw (coupling) 3 1 1 1 1 6 - 9
132 Coupling hub 3 1 1 1 1 6 - 9 A210-35-128
133 Baffle 3 1 1 1 1 6 - 9 A210-35-130
201 Air bleed assembly 1 1 1 1 1 1, 20 A652-01-005
202 Inlet valve assembly 1 1111 10
202-1 Valve cover 4 1111 10
202-2 Piston 4 1111 10
202-3 Valve pad 4 1111 10
202-4 Bush 4 1111 10
202-5 'U' seal 4 1 1 1 1 1, 6 - 10, 20
202-6 O-ring: 49.5 i.d. x 3.0 section 4 1 1 1 1 1, 6 - 10, 20 237-24-071
202-7 O-ring: 7.6 i.d. x 2.4 section 4 1 1 1 1 1, 6 - 10, 20 237-12-039
202-8 O-ring: 32.5 i.d. x 3.0 section 4 1 1 1 1 1, 6 - 10, 20 234-24-070
203 Gas ballast control assembly 1 1 1 1 1 A652-01-008
203-1 Gas ballast knob 1 1111
203-2 Filter 1 1111
203-3 O-ring: 14.6 i.d. x 2.4 section
(gas ballast control
1 1 1 1 1 1, 6 - 9, 20 H021-20-036
203-4 O-ring: 21.5 i.d. x 3.0 section
(gas ballast control)
1 1 1 1 1 1, 6 - 9, 20 237-24-073
204 Mode selector assembly 1 1 1 1 1 A652-01-009
204-3 O-ring: 9.6 i.d. x 2.4 section
(mode selector)
1 1 1 1 1 1, 6 - 9, 20
206 Adaptor 1 1111
208 Top plate 1 1 1 1 1 A210-35-125
209 Oil pressure valve 1 1 1 1 1 1, 20
210 Gas ballast check valve 1 1 1 1 1 1, 6 - 9, 20 A265-01-036
211 Spring (valve pad) 1 2 2 2 2 1, 6 - 9, 20
212 Spring (gas ballast control) 1 1 1 1 1 1, 6 - 9, 20
213 Spring (inlet valve) 1 1 1 1 1 1, 6 - 10, 20
215 Printed gasket (cartridge) 3 1 1 1 1 1, 6 - 9, 20 A271-60-006
216 Printed gasket (top plate) 1 1 1 1 1 1, 6 - 9, 10, 20 A271-60-00
217 Dump valve 1 1 1 1 1 1, 6 - 9, 20
219 O-ring: 57.6 i.d. X 2.4 section
(cartridge)
1 1 1 1 1 116-9 H021-22-055
220 O-ring: 21.5 i.d. x 3.0 section
(mode selector)
1 1 1 1 1 1, 6 - 9, 20 237-24-073
222 Shouldered washer (gas ballast) 1 1 1 1 1 1, 20
224 Screw: cap-head M6 x 20
(top plate securing)
1 4444
225 Screw: cap-head M6 x 40
(cartridge securing)
1 3333
226 Restrictor: M6 1 1111
301 Exhaust flange assembly 1 1 1 1 1 A652-01-007
301-1 Exhaust flange 1 1111
Table 1 - Parts list (continued)
Item
No.
Description Fig
Quantity
Kit No.(s) Part No.
RV3 RV5 RV8 RV12
