Edwards RV8 - Figure 5: Three-Phase Electrical Connections: 200-230 V; Figure 6: Three-Phase Electrical Connections: 380-460 V

Figure 5 Three-phase electrical connecons: 200-230 V
L1
L2
L3
E
W2
U2
V2
W1
V1
U1
B
A
CS/1109/A
1
A. Starter/contactor B. Motor terminal-boxA. Starter/contactor B. Motor terminal-box
1. Links1. Links
Figure 6 Three-phase electrical connecons: 380-460 V
L1
L2
L3
E
W2
U2
V2
W1
V1
U1
B
A
CS/1110/A
1
A. Starter/contactor B. Motor terminal-boxA. Starter/contactor B. Motor terminal-box
1. Links1. Links
03/2021 - ©Edwards Limited
Page 31A65201880_AA
A65201880_AA - Installaon
