3. Voltage Low Limit
The Frequency display will indicate “Volt” and the Voltage display shows “LO”. Press the
or key from the Current display to adjust the low limit voltage within the range of 0 -
310V.
4. Frequency HI Limit
The Frequency display will indicate “FrEq” and the Voltage display shows “HI”. Press the
or key from the Current display to adjust the high limit frequency within the range of 40 -
450Hz. When the frequency is set in the range of 40 - 99.9Hz, the resolution is 0.1HZ/STEP
whereby the setting is done in 100HZ - 450Hz range, the resolution becomes 1HZ/STEP.
5. Frequency Low Limit
The Frequency display will indicate “FrEq” and the Voltage display shows “LO”. Press the
or key from the Current display to adjust the low limit frequency within the range of 40 -
450Hz. When the frequency is set in the range of 40 - 99.9Hz, the resolution is 0.1HZ/STEP
whereby the setting is done in 100HZ - 450Hz range, the resolution becomes 1HZ/STEP.
6. Over Current Fold Back
The Frequency display will indicate “OC” and the Voltage display shows “Fold”. press the
or key from the Current display to select ON/OFF for the output status. (The same
method applied as voltage setting). Setting On, When output current is higher than “HI-A”
current setting current value, it will keep constant HI-A setting current value output.
