ef cooling Ernst H. Furrer AG Operating manual
5-18 Chapter page Issue: 07 / 2015 Cooling unit EVO 45, 0390.013
5 Installation and assembly
5.1 Safety
Suspended loads can fall.
Never step or remain under suspended loads.
Non-observance of this instruction can lead to fatal injury.
Free intake and blow-out of the cooling air and an adequate air exchange for heat
dissipation from the assembly site of the cooling unit must be ensured.
5.1.1 Personnel qualification
This cooling unit must only be installed and fitted by personnel who fulfil the following
requirements:
• Have read and understood Chap. 2 Safety
• Have completed basic mechanical and electrical training
5.2 Energy connections
The energy connections must be provided by the operating company. Refer to Chap. 13.1
Technical data for the required energy connections and connecting points.
The operating company is responsible for ensuring that the electrical connections are
safeguarded and implemented in accordance with the country-specific regulations.
The cooling unit must be connected in accordance with the electrical diagram supplied.
5.3 Installation
The cooling unit must be installed in a frost-free room on an even, horizontal surface and with
the requisite load-bearing capacity. There is no requirement for securing the foundations, the
use of underliners or vibration absorbers. Pipes must be flexibly connected with the cooling unit
by means of compensators or hoses.
Operation in frost conditions and installation outdoors require additional measures:
- Optional heating kit and permanent power supply
- Weather-resistant housing, rain protection
- Suitable antifreeze mixture
Observe the minimum distances during installation in order for the cooling unit to function in a
fault-free manner.
See Chap. 13.4 Drawings
