Unit type: Serial number:
Refrigeration data
Updated 01.06.2015 FRLO
Cooling capacity kW at (to / tc) 3/60 °C
Condensing capacity kW
Number of refrigeration circuits
Refrigerant
Compressor Quantity
Type
Power consumption kW total 20.6 kW
Current consumption A total 30.6 A
Condenser Type
Airflow
Quantity of fans Type:
Power consumption kW total 3.30 kW
Current consumption A total 6.30 A
Medium to be cooled Propylenglykol
Medium to be cooled Tank capacity
Pump Type
Quantity 1
Flow rate 125 l/min at 6.5 bar
Max. delivery height 7.0 bar Bypass 6.6 bar @ 7.2m3/h(120L/min)
Power consumption 4.00 kW total 4.00 kW
Current consumption 7.20 A total 7.20 A
Heat exchanger SWEP Type
Quantity 1
Flow rate 150 l/min Pressure loss 40 kPa
Control
High pressure control Typ Set 40 °C P-Band 10 K
Temperature control Typ Set 6 °C P-Band 1 K
Safety device
High pressure monitoring Typ OFF 26 bar ON man. bar
High pressure safety switch Typ OFF 27 bar ON man. bar
Low pressure monitoring Typ OFF 1 bar ON man. bar
Antifreeze monitoring Typ OFF -18 °C ON -15 °C
Flow switch Typ OFF l/min ON l/min
Limitation of use (consumer circuit)
Cooling circuit from 5 °C to 7 °C
Limitation of use (refrigeration circuit)
Ambient temperature from -15 °C to 45 °C
Evaporating temperature from -5 °C to 15 °C
Condensing temperature from 30 °C to 60
°C
max. operation pressure (PS) 28 bar PED category II
Power supply Voltage 3x460 V Fuse: 63 A
Frequency 60 Hz Starting current: 150 A
Contol 24 Vdc
Total power consumption
P
Operation
27.9 kW
P
MAX
31.3 kW
Total curent consumption
I
Operation
44.1 A
I
MAX
47.4 A
Weight 1000 kg
Length 2590 mm
Width 1000 mm
Height 1935 mm
Circuit Forward 1 1/2"
Return 1 1/2"
Hydraulic data (Producer circuit)
