Technical data / US units
Unit type: Serial number:
Refrigeration data
Updated 01.06.2015 FRLO
Cooling capacity kW at (to / tc) 37/140 °F
Condensing capacity kW
Number of refrigeration circuits
Refrigerant
Compressor Quantity
Type
Power consumption kW total 20.6 kW
Current consumption A total 30.6 A
Condenser Type
Airflow cfm
Quantity of fans Type:
Power consumption kW total 3.30 kW
Current consumption A total 6.30 A
Medium to be cooled Propylengl. / Water
Medium to be cooled Tank capacity
Pump Type
Quantity 1
Flow rate 33 US gpm at 94 psi
Max. delivery height 102 psi Bypass 96 psi at 32 US gpm
Power consumption 4.00 kW total 4.00 kW
Current consumption 7.20 A total 7.20 A
Heat exchanger SWEP Type
Quantity 1
Flow rate 39 US gpm Pressure loss 5.8 psi
Control
High pressure control Typ Set 104 °F P-Band 10 K
Temperature control Typ Set 45 °F P-Band 1 K
Safety device
High pressure monitoring Typ OFF 377 psi ON man. psi
High pressure safety switch Typ OFF 392 psi ON man. psi
Low pressure monitoring Typ OFF 15 psi ON man. psi
Antifreeze monitoring Typ OFF -0.5 °F ON 5 °F
Flow switch Typ OFF l/min
ON l/min
Limitation of use (consumer circuit)
Cooling circuit from 41 °F to 45 °F
Limitation of use (refrigeration circuit)
Ambient temperature from 5 °F to 113 °F
Evaporating temperature from 23 °F to 59 °F
Condensing temperature from 86 °F to 140 °F
max. operation pressure (PS) 406 psi PED category II
Power supply Voltage 3x460 V Fuse: 63 A
Frequency 60 Hz Starting current: 150 A
Contol 24 Vdc
Total power consumption
P
Operation
27.9 kW
P
MAX
31.3 kW
Total curent consumption
I
Operation
44.1 A
I
MAX
47.4 A
Weight 2205 lb
Length 102 "
Width 39 "
Height 76 "
Circuit Forward 1 1/2"
Return 1 1/2"
Hydraulic data (Producer circuit)
