EF EVO 45 - Page 73

11.1 11.2 11.3 11.4 11.5 11.6 11.7 11.8
=ANLAGE
+ORT
Blatt Nr.
11
Idx.
-
Schema Nummer
Name:
Erstellt am: a
Geprüft am:
0390.013_ES
Projekt/Kunde
Adresse (Ort)
HP Indigo 10000
Titel
Maschinentyp
general alarms
10.06.14
MILI
Name:
11.06.14
FRLO
b
c
d
compressor release 1 & 2
Maschinenart
EVO 45 60Hz. Version
Projekt Nr.
10< Bl. > Bl. -
Bl. total
11
10.9
PE
10.9
24VDC+
10.9
24VDC-
J16
C9 NO9 C9NO10 NO11
J17
NO12 C12 NC12
J18
NO13 C13 NC13
204203
SAMMELALARM
GENERAL ALARMS
ALARME GENERALE
ALLARME GENERALE
DE ALARMA GENERAL
EXTERN max. +24Vdc
X2
202
VERDICHTER 2
COMPRESSOR 2
COMPRESSEUR 2
COMPRESSORE 2
COMPRESOR 2
VERDICHTER 1
COMPRESSOR 1
COMPRESSEUR 1
COMPRESSORE 1
COMPRESOR 1
7.6
HS
AWG 18 yellow
AWG 18 blue
AWG 18 blue
AWG 18 yellow AWG 18 yellow
11H7
1
2
206
205
ALARM LED
ALARM LED
ALARME LED
ALLARME LED
ALARMA LED
OPTION
REMOTE BOX
11E3
L N
10 W
0.24 A
HEIZUNG EXPANSIONSVENTIL
HEATING EXPANSIONVALVE
CHAUFFAGE DETENDEUR
RISCALDAMENTO VALVOLA ESPANSIONE
CALENTEMIENTO VALVULA EXPANSION
21 22
1 2
3 4
5 6
13 14
31 32
43 44
11K1
A1
A2
3.3
3.3
3.3
4.7
21 22
1 2
3 4
5 6
13 14
31 32
43 44
11K2
A1
A2
3.5
3.5
3.5
4.8
AWG 18 blue
OPTION
REMOTE BOX
AWG 18 blue
11K3
A1
A2 14 0V
13
41
X1
40
www.macschema.ch, E6.0, (0092)
