MINAC Systems Revision A
USER MANUAL 31 January 2005
63860.doc
© For reproduction rights, see cover page.
1 INTRODUCTION
This manual provides step-by-step operation instructions for the MINAC standard
25/40 and 50/80 systems and MINAC 25 Twin systems. It also contains safety
information and instructions, and some simple corrective measures.
The operation instructions must be read thoroughly before the equipment is used.
Using these instructions, MINAC operators should be able to undertake correct and
safe operation. However, only qualified personnel should carry out general trouble-
shooting and maintenance tasks.
Figure 1. MINAC Standard 25/40 Induction Heater.
Figure 2.
MINAC Standard 50/80
Induction Heater with
HHT 400S.
Display and
Switches and
Supply
power cable
HHT
Output
power cable
