SPECIFICATION
FAQS
If I remove the batteries will I lose the information on the display?
If you need to change or remove the batteries, the display has an internal memory, so
information stored on the display will not be lost.
How do I reset the display (clear the data and start again)?
Press Mode and Date Buttons simultaneously and hold for two seconds ‘clr’ will be
displayed on the screen.
How far does the device transmit?
Transmitters work up to around 40 meters within the home. The 433MHz range is well suited
for in home use. This can cover three floors, and also well suited to buildings where meters
are outside the main building.
I have three dashes (- - -) showing on the display. What does this mean?
Move the display closer to the transmitter and press the Link Button. If the dashes remain
on the display this would indicate the transmitter and receiver are not communicating.
Please contact efergy Customer Service to help locate the problem.
Backlight appears to work sometimes, and not other times. Is my display broken?
No. The backlight is on a timer to save battery life. The display should work at darker
periods of the day, when any buttons are pressed.
For more information about the e2 and the elink software, go to www.efergy.com
Model Name/Number: efergy e2 1.0
Frequency: 433.52MHz
Transmission Time: 6s. 12s. o 18s.
Transmission Range: 40m-70m
Voltage Range (in the sensor): 110V-400V
Measuring Current: 50mA-95A
Accuracy: >90%
The LED backlight will be activated from 18:00Hrs to 6:00Hrs.
Carbon ratio: 0,50 kg. CO2 / kWh
