Effekta ES3300 - Page 50

Photovoltaic Solar Inverter Series ES
Commissioning
ES series
50
Fig. 7-4 – 5 Display K - Temperature of cooling element in °F
Fig. 7-4 - 6 Display L - String A voltage
Fig. 7-4 - 7 Display M - String B voltage
Fig. 7-4 - 8 Display N - String A current
Fig. 7-4 - 9 Display O - String B current
