CPAT FLEX User Manual (ARD4) CPAT FLEX User Manual (ARD4)
8.2 DRV4 Specications 8.3 DRV3 Lite Specications
ELECTRICAL Details
Detector type Dual-band digital receiver / demodulator
Frequency range
Agile 118 to 140 MHz (mid-band)
Agile 600 to 860 MHz (LTE-band)
Tuning resolution 100 Hz
Level range
2 to 4,000 μV/m @ 3 meters (mid-band)
5 to 4,000 μV/m @ 3 meters (LTE-band)
Level accuracy
±1.5 dB mid-band
±2.5 dB LTE-band
System tag
AM [10 to 110 Hz]
DSB-SC modulation 3,500 to 7,000 Hz
Video NTSC (mid-band only)
Measurement units μV/m and dBμV/m
Power Via the ARD4 port (+ 5 VDC 0.8 A)
Communication port ARD4 port (proprietary) and USB serial port
Storage temperature -20˚ to +40˚ C / -4˚ to +104˚ F
Operating temperature 0˚ to +60˚ C / -32˚ to +140˚ F
Maximum relative
humidity
80% for temperatures up to 31˚ C (88˚ F) decreasing linearly to 50%
relative humidity at 40˚ C (104˚ F)
PHYSICAL Details
Dimensions [H x W x D] 3.3 cm x 11.2 cm x 22.3 cm / 1.3” x 4.4” x 8.8”
Weight 770 g / 27 oz
* Specications subject to change without prior notice.
ELECTRICAL Details
Detector type Dual-band digital receiver/demodulator
Channel tuning Congurable via USB port and/or Bluetooth
Frequency range Agile from 118 to 140 MHz (mid-band)
Frequency range Agile from 600 to 860 MHz (LTE-band)
Tuning resolution 100 Hz
Level range
2 to 4,000 μV/m @ 3 meters (mid-band)
5 to 4,000 μ/Vm @ 3 meters (LTE-band)
Measurement units μV/m and dBuV/m
Level accuracy ±1.5 dB (mid-band) ±2.5 dB (LTE-band)
Communication port USB serial port and Bluetooth
Adjustable audible tone Yes, varies with leak intensity. Can be muted
System tag
AM modulation 20-110 Hz
DSB-SC modulation 3480-7000 Hz
Video NTSC (mid-band only)
RF level scale display Single scale from 0 to 4,000 μV/m
Operation time 6 hrs. continuous on battery power
Operating temperature* -20°C to +40°C (-4°F to +104°C)
Charging temperature* 0°C to 45°C (32°F to 110°C)
Battery charge time 2.25 hrs. for full charge
Storage temperature -20°C to +45°C (-4°F to +113°C)
Maximum relative
humidity
80% for temperatures up to 31°C (88°F) decreasing linearly to 50%
relative humidity at 40°C (104°F)
PHYSICAL Details
Dimensions 17 cm x 8 cm x 6.7 cm / 6.7” x 3.1” x 1.6” [H x W x D]
Weight 450 g / 16 oz
* Specications subject to change without prior notice.
