Efka DC 1550 - Page 18

EFKA AB320A5200
20
Adapter cord for PFAFF models 563, 953, 1050, 1180 without thread monitor
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 0
Setting the functions of the keys Input in4 ! Set parameter 243 = 12
Input in5 ! Set parameter 244 = 16
*) Rear view (soldering side) of 37-pin plug (ST2) and of the remaining sockets.
KL2261
