Efka DC 1550 - Page 19

EFKA AB320A5200
21
Adapter cord for PEGASUS models W500/UT, W600/UT/MS with or without stitch condensing
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 5
Setting the functions of the keys Input in1 ! Set parameter 240 = 7
Attention!
When using this adapter cord on a Pegasus machine, the 9-core cable no. 742373-91 must be
removed from the machine!
Adapter cord for PEGASUS backlatch machines
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 8
Setting the functions of the keys Input in1 ! Set parameter 240 = 6
(Automatic setting) Input in3 ! Set parameter 242 = 10
*) Rear view (soldering side) of 37-pin plug (ST2). Front view (component side) of the remaining plugs/sockets.
