Efka DC 1550 - Page 22

EFKA AB320A5200
24
Adapter cord for UNION SPECIAL models CS100 and FS100
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 4
Setting the functions of the keys Input in1 ! Set parameter 240 = 6
Input in3 ! Set parameter 242 = 6
in1 = Input machine run blockage for thread trimming control proximity switch
in3 = Input machine run blockage for thread monitor
Adapter cord for UNION SPECIAL model 63900AMZ
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 10
