Efka DC 1550 - Page 23

EFKA AB320A5200
25
Adapter cord for UNION SPECIAL model 34700 with stitch lock
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 5
Setting the functions of the keys Input in8 ! Set parameter 247 = 7
Input in9 ! Set parameter 248 = 6
*) Rear view (soldering side) of 37-pin plug (ST2) and of the remaining sockets.
