EFKA AB320A5200
75
Supplier Level
Code no. 311 with control operation
Code no. 3112 with control panel operation
Parameter Designation Unit max min Preset Ind.
307 A1 Signal A1 On/Off 1 0 0 A
308 dA1 Stitches delaying signal A1 stitches 999 0 0 A
309 cA1 Stitch counting during signal A1 stitches 999 0 0 A
310 AA2 Selectable power transistors for signal A2 12 0 0 A
0 = No function
1 = Signal on output M1
2 = Signal on output M2
3 = Signal on output M3
4 = Signal on output M4
5 = Signal on output M5
6 = Signal on output M6
7 = Signal on output M7
8 = Signal on output M8
9 = Signal on output M9
10 = Signal on output M10
11 = Signal on output M11
12 = Signal on output VR
311 So2 Issue signal A2 3 0 0 A
0 = Signal until seam end (according to setting of
parameter 320)
1 = Signal over time
2 = Signal until seam end and drive stops
3 = Signal during stitch counting (according to setting
of parameter 319)
312 tr2 Starting point for signal A2 3 0 0 A
0 = Start at the beginning of the seam
1 = Start of the signal triggered by light barrier sensing
2 = Start of the signal when the drive stops at the seam
end
3 = Start from light barrier covered onwards at the
beginning of the seam
313 do2 Delay of signal A2 2 0 1 A
0 = No delay until signal On
1 = Delay over time until signal On
2 = Delay over stitches until signal On
314 dt2 Delay time until signal A2 On ms 2550 **) 0 0 A
315 St2 ON period of signal A2 ms 2550 **) 0 0 A
316 nA2 Speed mode when signal A2 is On 2 0 0 A
0 = Pedal controlled speed
1 = Limited speed n9
2 = Limited speed n11
317 A2 Signal A2 On/Off 1 0 0 A
318 dA2 Stitches delaying signal A2 stitches 999 0 0 A
319 cA2 Stitch counting during signal A2 stitches 999 0 0 A
320 bP0 Switch-off time of signals A1 and A2 1 0 0 A
0 = Signals effective until seam end
1 = Signals effective until pedal is in pos. 0 (neutral)
321 Std Suppression of the seam when 0 stitches are set 1 0 0 A
0 = Suppression Off
1 = Suppression On
322 dkn 0 = Correction seam Off 2 0 0 A
1 = Correction seam On
2 = Interruption of seam or pattern by thread trimmer
*) Depending on the selected mode. See table at the beginning of the List of Parameters!
**) When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit
value displayed must be multiplied by 10.
