Efka DC 1550 - Page 74

EFKA AB320A5200
76
Supplier Level
Code no. 311 with control operation
Code no. 3112 with control panel operation
Parameter Designation Unit max min Preset Ind.
323 FLn 0 = Sewing foot is not lifted after power On 1 0 0 A
1 = Sewing foot is lifted after power On
This function is enabled only if TEACH IN is On
324 ti 0 = Teach-in Off 1 0 0 A
1 = Teach-in On
Teach-in programming is possible only with V820.
Execution of pattern is possible without V820.
500 Sir Recall of Fast Installation Routine (SIR)
(see description on page 8!)
NA = Start of seam
LS = Light barrier uncovered or covered at the seam end
NE = Seam end
FA-E = End thread trimming operation
P=0 = Pedal in pos. 0 (neutral)
St = Stitches
Parameter 320 = 0 ! Signals enabled according to setting of parameter 301/311.
Parameter 320 = 1 ! Signals enabled until pedal is in pos. 0 (neutral).
