Z Series Assembly Manual
© 2023 EFT Electronic Technology Co. Ltd. All Rights Reserved.
Endin g :
1. After the above parts are installed, restore the front and rear drone upper and lower covers to their original positions.
2. F inally, use a level to adjust the motor, and then tighten t he screws. It is recommended to install the propellers when outdoor test.
Switch Spreading Tank
1. To disassemble t he sprinkler system, first disconnect the water pipes which connected to the water pump and the multi-function
cable, then take out the spray tank.
2. Put the spread tank with t he spreader into the drone body and fix it, then connect the spreading cable with the multi-function
adapter cable that fixed in drone body.
Tip ： This manual is only for assembly guide. Please refer to
Z Series User Manual
for detailed operation. If you have any questions,
please con tact EFT or an officially authorized agent.
