6.4.3 INTERFACE MENU DEFINITION

• BMS Parameter

• BMS Control

• Software Parameter

If you are experiencing any issues with the battery module or the BMS, please contact your distributor

for assistance or troubleshooting steps.

Interface Menu Definition

Item

Definition

BMS Monitoring

Real-time data and status monitoring of the BMS

BMS Parameter

BMS parameter setting management (restricted, unauthorized changes will

void warranty)

BMS Datalog

BMS operation data logging to PC (for manufacturer use)

Historical Record

Real time BMS operation data records (exportable)

Communication

Record of sending and receiving of battery pack data (exportable)

WARNING:

Although there are multiple tabs in the BMS Tools software, the following tabs

should not be tampered with as any unauthorized changes will void the warranty of this product

and risk damaging and/or rendering the product permanently inoperable.

Questions and Answers:

Need help?

Do you have a question about the EG4 LL and is the answer not in the manual?

EG4 LL Specifications

General

Nominal Voltage	51.2V
Nominal Capacity	100Ah
Energy	5.12 kWh
Max. Continuous Discharging Current	100A
Warranty	10 years
Cycle Life	6000 cycles @ 80% DoD
Communication	CAN, RS485
Scalability	Up to 16 in parallel
Operating Temperature	-4°F to 131°F (-20°C to 55°C)
Battery Type	LiFePO4
Protection	High Temperature, Low Temperature, Short Circuit
C Rating	1C
