EG4 LL User Manual

4
Voltage Accuracy
0.5%
Cycle
Measurement
For Cells/Module
Current Accuracy
3%
Cycle
Measurement
Measurement Range
+/-200A
SOC
5%
-
Integral Calculation
Power Consumption (Sleep & Off Mode)
<300uA
-
Storage/Transport
Power Consumption (Operating)
<20mA
-
Charging/Discharging
Communication Ports
RS485/CAN
Customizable
Maximum Modules in Parallel
16
Dimension (H×W×D)
6.1 in.×19 in.×20.2 in. (15.5 cm×48.2 cm×51.3 cm)
Weight
99.2 lbs. (44.5 kg)

EG4 LL Specifications

General

Nominal Voltage	51.2V
Nominal Capacity	100Ah
Energy	5.12 kWh
Max. Continuous Discharging Current	100A
Warranty	10 years
Cycle Life	6000 cycles @ 80% DoD
Communication	CAN, RS485
Scalability	Up to 16 in parallel
Operating Temperature	-4°F to 131°F (-20°C to 55°C)
Battery Type	LiFePO4
Protection	High Temperature, Low Temperature, Short Circuit
C Rating	1C
