COMPONENT LOCATIONSCOMPONENT LOCATIONS
SERIAL NUMBER LOCATIONSSERIAL NUMBER LOCATIONS
VIN - Chassis Number VIN - Chassis Number
e VIN number is located on the neck of the chassis.
1. Right or le side of frame.
Write this number in the VIN box on Page 3.
Engine Model & Serial NumberEngine Model & Serial Number
e engine model number and serial numbers are stamped
on the le side of the engine under the engine sprocket
cover.
Write this number in the Engine Number box on page 3.
HANDLEBAR LEVER CONTROLSHANDLEBAR LEVER CONTROLS
Clutch LeverClutch Lever
e clutch (A)(A) is located on the le side of the handlebar.
Hand Brake lever & rottle Hand Brake lever & rottle
e hand brake lever (A)(A) and throttle (B)(B) are mounted on
the right side of the handlebar.
Stop Switch Stop Switch
e stop (kill)(kill) switch (A)(A) turn o the engine. When this
button is pressed, the ignition circuit is turned o.
Start Switch (Electric Start Engine) Start Switch (Electric Start Engine)
e start switch (A)(A) turns on the engine. When this button
is pressed, the electric starter will engage to start the engine.
Once started, release the button.
