COMPONENT LOCATIONSCOMPONENT LOCATIONS
OPERATING CONTROLSOPERATING CONTROLS
Kick Start Lever Kick Start Lever
e kick start lever (A)(A) is mounted on the right side of the
engine. It is used to start the engine in case the electrical
starter system is non-functional.
Side (Kick) Stand Side (Kick) Stand
Push the side stand (A)(A) to the ground and tilt the mo-
torcycle to the le. Make sure the motorcycle is on solid
ground and the position is secure.
Fuel Valve Fuel Valve
OFF -OFF - In this position, the fuel valve is closed. No fuel can
ow to the carburetor.
Fig. 1Fig. 1
ON -ON - In this position, the fuel valve is open. Fuel can ow to
the carburetor. With the valve in this position, the tank will
be emptied. Fig. 2Fig. 2
Fig.1
Fig.2
