Ego Power+ HPW2000E - Operation

56V LITHIUM-ION PRESSURE WASHER — HPW2000E
9
PART NAME MODEL NUMBER
Premium Foam Cannon AFC2000E
DESCRIPTION
KNOW YOUR PRESSURE WASHER (Fig. A)
ASSEMBLY
INSTALLING THE HOLDER BRACKET ASSEMBLY
(Fig. B)
CONNECTING THE HIGH-PRESSURE HOSE
(Fig. C – Fig. D)
You may connect the high-pressure hose by one of the
following ways:
◾ Connect the high-pressure hose to the water outlet
port and the gun directly using threaded connectors
(Fig. C1 – Fig. C2);
◾ Connect the high-pressure hose to the water outlet
port and the gun using two quick-coupler sets to
achieve easy installation/removal (Fig. D1 – Fig. D2).
NOTE: The quick-coupler sets have been installed onto
the water outlet port, high-pressure hose, gun at the
factory.
CONNECTING THE LANCE AND WAND
(Fig. E1 – Fig. E2)
To disconnect, screw the wand from the lance and then
pull it out; loosen the knob on the lance and then pull
back the outer ring of the quick-coupler of the gun to pull
out the lance.
WARNING: Always hold the gun with one hand and
the lance with the other hand when disconnecting the
lance from the gun. Personal injury may result if the lance
falls.
CONNECTING A NOZZLE (Fig. F1 / Fig. F2)
NOTE:
The nozzles cannot be connected to the lance.
◾ Choose the 15° nozzle, 25° nozzle, 40° nozzle, or
Turbo nozzle to install onto the wand (Fig. F1).
◾ The rinse nozzle is connected to the gun directly
(Fig. F2).
WARNING: Always hold the gun with one hand and
the nozzle with the other hand when disconnecting the
nozzle from the gun. Personal injury may result if the
nozzle jumps out.
Use the table below to pick the right nozzle for the job.
Nozzle Selection Applications
Yellow 15° Nozzle
Clean small metal, concrete,
or wood surfaces.
Green 25° Nozzle
Clean larger metal, concrete,
or wood surfaces.
White 40° Nozzle
Clean wide metal, concrete,
wood, or vinyl surfaces.
Gray Rinse Nozzle
Rinse vehicles.
Rinse the detergent off of
metal, concrete, wood, or
vinyl.
Turbo Nozzle
Clean hard surfaces only. To
prevent surface damage, do
not use on cars and wooden
surfaces.
CONNECTING THE FOAM CANNON (Fig. G)
The foam cannon is connected to the gun directly.
To disconnect, pull back the outer ring of the quick-
coupler, and then pull out the foam cannon.
CONNECTING THE SIPHON HOSE (Fig. H1 – Fig. H2)
When using a water bucket (not provided) as a source of
water, connect the pressure washer to the siphon hose.
NOTE: Prell the bucket so when immersed lter does
not oat to the surface.
CONNECTING TO A GARDEN HOSE (NOT PROVIDED)
When using water tap (not provided) as a source of
water, connect the pressure washer to a garden hose
(notprovided).
OPERATION
APPLICATION
You may use this product for the purposes listed below:
◾ Cleaning dirt on automobiles, walls, oors, etc.
ATTACHING/DETACHING THE BATTERY PACK
Refer to corresponding battery packs and chargers
manuals for more details.
Fully charge before first use.
NOTE: Using one battery pack will not allow you
achieve TURBO speed. For best performance, we
strongly recommend use of two 5.0Ah or greater Ah
