56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2100SP/LM2100SP-FC/LM2100/LM2100-FC 41
◾
Place the folded mower upright on
the ground (Fig. 32c & 32d).
◾
Lubricate the deck-height adjustment
joint.
◾
For LM2100SP/LM2100SP-FC,
lubricate the bearings on the drive
shaft near the rear wheels and the
bearings in the front wheels
(Fig. 32c).
◾
For LM2100/LM2100-FC, lubricate
the bearings in both the rear and front
wheels (Fig. 32d).
32c
Bearing
Bearing
Drive shaft
Deck-Height
Adjustment Joint
Bearing
Bearing
For LM2100SP/LM2100SP-FC
32d
Bearing
Bearing
Deck-Height
Adjustment Joint
Bearing
Bearing
For LM2100/LM2100-FC
