56V LITHIUM-ION CORDLESS 20" CHAIN SAW — CS2000/CS2000-FC44
3. Use a 5/32ʺ (4.0 mm) diameter
round file and holder (available
separately). Do all of your filing at
the middle position of the guide bar.
4. Keep the file level with the top plate
of the tooth. Do not let the file dip or
rock.
5. Keep a correct sharpening angle of
30° between the file and the saw
chain (see Fig. 33 & 34). Always use
a file holder (available separately)
when sharpening saw chains by
hand. File holders have markings for
the sharpening angle.
6. Using light but firm pressure,
perform a stroke towards the front
corner of the tooth. Lift the file away
from the steel on each return stroke.
7. Make a few firm strokes on every
tooth. File all left-hand cutters in
one direction. Then move to the
other side and file the right-hand
cutters in the opposite direction.
Occasionally remove filings from the
file with a wire brush (Fig. 35).
WARNING:
A dull or improperly
sharpened chain can cause excessive
motor speed during cutting, which may
result in severe motor damage.
WARNING:
Improper chain sharpening increases the potential of kickback.
WARNING:
Failure to replace or repair a damaged chain can cause serious
injury.
34
33
5/32" (4.0 mm)
Round File
Filing Direction
Cutter tooth
Sharpening
Angle: 30°
35
Left Hand
Cutters
Right Hand
Cutters
