56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC36
CLEANING THE MOWER
WARNING: Always remove the battery pack when servicing or transporting the
mower.
The underside of mower deck should be cleaned after each use, as grass clippings,
leaves, dirt and other debris will accumulate. This accumulation is undesirable, as it will
promote rust and corrosion.
Remove any build-up of grass and leaves on or around the drive shaft and motor fan
(do not use water). Wipe the mower clean with a damp cloth.
REMOVING THE BLADE
WARNING: Always protect your hands by wearing heavy gloves or wrapping
the cutting edges with rags or other materials when performing any maintenance on
the mower blade. Always remove the battery pack when servicing or transporting the
mower.
NOTICE: The following tools are required for replacing the blade:
◾
9/16” (14mm) wrench
◾
torque wrench
◾
Manual screwdriver or metal rod with a diameter of 5/16” (8mm)
◾
Manual screwdriver or metal rod with a diameter 1/4” of (6.35mm) or less
1. Stop the motor; remove the battery
pack from the mower.
2. Turn the mower on its side.
3. While wearing protective gloves,
place a metal rod (e.g., a 3.5” length
screw bit) with diameter less than
5/16” (8mm) into the fixing hole to
act as a stabilizer (Fig. 22).
4. Use a 9/16 inch (14mm) wrench to
turn the blade bolt counterclockwise to loosen it.
22
Stabilizer
Loosen
