56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC 39
7. Place a metal rod (e.g., a 3.5” length
screw bit) with diameter less than
1/4 inch (6.35mm) into the aligned
holes to act as a stabilizer. Place
another metal rod (e.g., a 3.5” length
screw bit) with diameter less than
5/16” (8mm) into the fixing hole to
act as another stabilizer (Fig. 29).
8. Use a 9/16 inch (14mm) torque
wrench (not included) to tighten the
bolt clockwise. The recommended torque for the blade bolt is 36-43 ft-lb
(49-59Nm).
SHARPENING THE BLADE
WARNING: Always protect your hands by wearing heavy gloves or wrapping
the cutting edges with rags or other materials when performing any maintenance on
the mower blade. Always remove the battery pack when servicing or transporting the
mower.
WARNING: Use proper eye protection while removing, sharpening, and installing
the blade.
WARNING: A worn, cracked, or damaged blade can break and pieces of the
damaged blade can become dangerous projectiles. Thrown objects can cause serious
injury. Inspect the blade regularly and do not operate the mower with a worn or
damaged blade.
NOTICE: Keep the blade sharp for best mower performance. A dull blade does not cut
grass cleanly or mulch properly.
A dull blade can be sharpened, but a blade that is excessively worn, bent, cracked, or
otherwise damaged must be replaced. A worn or damaged blade can break, causing
blade pieces to be thrown from the mower.
If the blades are found to be bent, take the lawn mower to an authorized EGO service
center for inspection.
THIS SIDE FACING GRASS
29
Stabilizer 2
Stabilizer 1
Tighten
